55mm Disc Wheels Without logos

  • Clincher tubeless ready
  • 18.35mm internal rim width, 25mm external width
  • Sapim CX-Ray spokes
  • Sapim Secure Lock nipples
  • Recommended Tire Size: 25mm – 28mm
€695,95
€695,95
Disc Type: Centerlock
Driver Body Type: Shimano 11 Speed
Subtotal: €695,95
10 customers are viewing this product

Fast Delivery

15-Year Quality Assurance

2-year Warranty

55mm Disc Wheels Without logos

55mm Disc Wheels Without logos

€695,95

55mm Disc Wheels Without logos

€695,95
Disc Type: Centerlock
Driver Body Type: Shimano 11 Speed

Everyone wants to go fast for less effort, and that is why we created for you deep section carbon fiber wheels. Our Aero 55 disc wheelset is the ideal wheelset if you want great aero gains while still being able to ride on windy days.

Aero range is built off the back of our Fast and Light series of wheels. We knew we had to keep the Aero series just as stiff, just as strong, still tubeless ready but we wanted to make them lighter. We made them lighter by changing our carbon fiber layup.

Instead of using solely Toray T700, we now use a mix of carbon fiber in the layup process. We mix Toray T700 with T800 carbon fiber cloth, and that allowed us to reduce the wheelset’s weight by around 100g, while still keeping all the other great qualities.

It is just not the rim that is new. We have also created a new disc brake hub, the ICAN D01 hubset. The new hubset is lighter than the hubs we previously used and is available in both Centerlock and 6-bolt fitment so you can be sure to fit your rotors on there. Axle wise we have gone with thru axles. Thru axles allow us to build you a stiffer wheelset and you’ll find we have gone for 100 x 12mm at the front and 142 x 12mm at the rear.

We finished the wheelset off by lacing it with Sapim CX-Ray spokes. Sapim have been making great spokes for over a century now, and we feel their knowledge for making light, and strong spokes is unparalleled.

Features

Wide Rim Tech

25mm rim wide creates a better, more stable support, while the shape of the tire and rim together creates regular, stable air flow, in short, more aerodynamics, less attrition. provides an ideal basis for 25/28mm tires, the sizes currently popular.

2-Way Clincher Tubeless. Tubes or No-Tubes

Use either traditional tires with tubes, or tubeless tires without tubes. Tubeless tires can provide lower rolling resistance and better protection from punctures.

Sapim CX-RAY As light as a titanium spoke

The CX-Ray still receives the best results in fatigue testing of any spoke. The CX-Ray aero spoke combines excellent aerodynamics with low weight and great strength. Not only are they more aerodynamic, they also make wheels lighter and stronger. Its unique strength and flexibility make the CX-Ray suitable for most bicycle disciplines. CX-Ray spokes are used by top bike racers and triathletes around the world.



Specification

Type  Carbon Racing Bike Wheelset
Material  Toray T700 & T800
Size  700C
Rim

 Finish: UD Matt
 Drills: 24/24 Holes
 Width: External: 25mm

 Internal: 18.35mm

Depth  55mm
Profile  Clincher Tubeless Ready
Hub  D01 Hubs 12x100/12x142mm
Disc Type  Centerlock/6 Bolts
Spoke  Sapim CX-Ray Spokes
Spoke Count  Front: 24   Rear: 24
Spoke Pattern  Front: 2-cross
 Rear: 2-cross
Nipple  Alloy  Color: Black
Cassette Compatibility  Shimano 11 speed
Wheelset Weight

 Total: 1467+-20g (Centerlock, 12x100/12x142mm)

 Front: 657+-10g   Rear: 810+-10g

Brake Surface  No Braking Surface
Recommended Tyre Size  700 x 25-45mm
Rider Weight Limit  242lbs/110kg
Guarantee  2 years
Free

Rim Tape

Valves

Packing Size  81.5cm x 17cm x 65.5cm



Recommended Tire Pressure

Below Chart is our recommended tire pressure,you can see more click here

  STANDARD CLINCHER TIRE WITH INNER TUBE TUBELESS TIRES
≤ 65 KG RIDER 23mm - 95/100 psi
25mm - 90/95 psi
28mm - 85/90 psi
23mm - 90/95 psi
25mm - 85/90 psi
28mm - 80/85 psi
65 - 75 KG RIDER 23mm - 100/105 psi
25mm - 95/100 psi
28mm - 90/95 psi
23mm - 90/95 psi
25mm - 85/90 psi
28mm - 85/90 psi
75 - 85 KG RIDER 23mm - 101/106 psi
25mm - 96/101 psi
28mm - 91/96 psi
23mm - 95/98 psi
25mm - 90/95 psi
28mm - 85/90 psi
85 - 95 KG RIDER 23mm - 104/109 psi
25mm - 99/104 psi
28mm - 94/100 psi
23mm - 95/99 psi
25mm - 90/95 psi
28mm - 88/95 psi


IMPORTANT - Please check, and never exceed, the maximum recommended tire pressures on the side of your tire.

Warranty Policy

Every ICAN frame and rim has a useful product life cycle. Each bike, frame and rim will have a unique identification number and warranty card. Complete the provided card and warranty form, and send them to us. Failure to use the provided warranty card will void your warranty. Save your dated receipt for proof of purchase.

Product Group:

Frame and Rim

Applies to all ICAN and Triaero brand bike frame, and FL Max series, AERO Series, and Alpha series rim.

Coverage:

2-year warranty from the date of purchase.

Conditions:

  1. If any manufacturing defect occurs within 30 days of the date of purchase, is obligated to replace the rim(s) and also pay for the shipping cost. If any manufacturing defect occurs after 31 days and up to 2 years, ICAN is obligated to replace the product(s). The product owner is responsible for shipping costs.
  2. If we no longer make the rim you purchased we’ll upgrade you to the newest equivalent model at no extra cost.
  3. The Warranty program is not transferable and only applies to the initial purchaser.

This warranty does not cover:

  • Normal wear and tear (bearings, spokes, nipples, brake tracks, tires, inner tubes, pawls, freehub, seals, rim tape etc.)
  • Products which have been incorrectly installed and/or adjusted.
  • Issues brought about by neglect or poor maintenance.
  • Surface finish and cosmetic treatments (anodizing, decals, etc.)
  • Crash damage.
  • Consequential or incidental damages (where applicable)
  • Products purchased “second-hand”, “used”, “as-is”, or expressly “without warranty”
  • Counterfeit products
  • Unauthorized modification or alteration, including without limitation, any repair performed by anyone other than ICAN or an ICAN-authorized servicer, or outside of the recommendations of ICAN Customer Service

Tips:Please contact the official support of ICAN at the first time when you find a quality problem. Please do not repair our products privately, otherwise we will not bear any warranty.

The following will void your warranty

  • Misuse (Jumping, trick riding, etc.)
  • Modification of wheels
  • Tire pressure exceeding 140psi
  • Improper assembly
  • Installation of parts or accessories not originally intended for, or not compatible with the wheelsets sold.
  • Use of brake pads not designed for carbon wheels

More details can be known from "Warranty & Return".
